FB Mondial Piega Euro 5
Introducing the PIEGA – an impressive 125cc motorcycle designed by Rodolfo Frascoli and developed at the F.B Mondial style and design centre. This bike boasts unique geometries and engineering, setting it apart from other motorcycles in its class. Notable features include the innovative double superimposed front lights, and the fins for the vents, which give the PIEGA a distinct personality. Other advanced features of the PIEGA include a modern TFT for running data control, and the Dell’Orto injection system, which is specifically designed to deliver outstanding performance. Its sleek and streamlined “tail” and rear lights positioned on the license plate holder make it a standout on the road. Under the hood, the PIEGA is powered by a single cylinder, 4 stroke, DOHC, 4 valves engine with a capacity of 124cc. It has a bore x stroke of 58 x 47 mm, and a compression ratio of 12.0:1. The bike can reach a max power of 10.0 kW at 9750 rpm, and a max torque of 10.5 Nm at 8000 rpm. The engine is lubricated by a wet sump, and features a liquid cooling system, along with electronic fuel injection and electric starting. The PIEGA has a 6-speed transmission, and a 9.5L fuel tank. It weighs 135 kg in running order and is equipped with a 4 piston radial calliper front brake with a 300 mm disc diameter, and a 1 piston floating calliper rear brake with a 220 mm disc diameter. Its front and rear wheels have sizes of 2.75×17″ and 3.50×17″, respectively, with front and rear tires of 110/70-17″ and 140/70-17″. The bike can seat up to two people, and has a length of 2000 mm, width of 810 mm, height of 1070 mm, wheelbase of 1340 mm, ground clearance of 190 mm, and seating position height of 820 mm. Its suspension system consists of a Ø40 mm USD fork with a travel of 97 mm in the front, and a single shock absorber with a travel of 120 mm in the rear. Overall, the PIEGA is an exceptional motorcycle that offers a combination of advanced features, performance, and unique design elements that are sure to turn heads on the road. The Piega presents itself as an affordable, A1 license-friendly option that brings some sportiness and futuristic styling to the table.
**Please note, while every effort is made to ensure images are kept up to date, some models can change without prior notice. Images are for illustrative purposes but will give a fairly accurate idea of what the product will look like. **
FB Mondial Piega Finance – APPLY HERE
Finance Calculator
[repayments]
Representative example: borrowing £3000 over 36 Months with a representative APR of 24.9%, the amount payable would be £115.21 a month, with a total cost of credit of £1,147.56 and a total amount payable of £4,147.56.
*This finance calculator is for illustration purposes only. The actual interest rate you receive from the finance provider will depend on your individual circumstances. The above example excludes any fees that may be charged by the lender.
Video
*please note, the video shown may be a previous model and should not be considered the latest model. Usually there will be only minor changes if any. If in doubt, please contact us.
Warranty Information
Service Schedule
In order to maintain the warranty, vehicles are required to be serviced at the correct intervals. Failure to do so will render the warranty void. It is highly recommend that the user has the vehicle maintained to ensure increased safety & vehicle longevity. It is possible to buy service kits here if you prefer to maintain your vehicle yourself however your warranty will become void unless a VAT registered garage carries out each service and validates this by filling in the service book accordingly.
125cc Motorcycles Insurance Discount Codes
Cheap motorbike insurance seems to be a bit of a hit or miss, however we have a top tip to get the best price possible and then a bit more. If you are lazy like 90% of the population using a comparison website will be your ‘go to’. But, if you actually call any of the insurance companies below you will be guaranteed to get a better deal. Insurance companies have to pay the comparison sites a big commission and they can then pass that discount onto you instead. If you use the discount code you will be not only getting yourself cheaper motorcycle insurance, but we get a little something too… win win for everyone, what have you got to lose? We have included the telephone numbers and reference numbers below, its just a simple phone call.
- Lexham Insurance (discount code auto fills when using the link – opens new tab)
- BikeSure Insurance (discount code auto fills when using the link – opens new tab)
FB Mondial Piega Specifications
Engine Specifications Mondial Piega 125cc ABS 2023
ENGINE TYPE
Single cylinder, 4 stroke, DOHC, 4 valves / Single cylinder, 4 stroke, DOHC, 4 valves
DISPLACEMENT
124cc
BORE X STROKE
58 x 47 mm
COMPRESSION RATION
12.0: 1
RATED OUTPUT
14BHP
MAX. TORQUE
10.5 Nm at 8000 rpm
LUBRICATION
Wet sump / Wet sump
FUEL SUPPL
Electronic injection / EFI
EXHAUST SYSTEM
Euro 5 Compliant
CERTIFICATION
Euro 5
GEARBOX
6 Speed
FINAL DRIVE
Chain
IGNITION
Electric starter / Electric starter
COOLING SYSTEM
Liquid Cooled
STARTING
Electric
PRIMARY DRIVE
Chain
Chassis Specifications Mondial Piega 125cc ABS 2023
FRONT SUSPENSION
USD fork Ø40 mm / Ø40 mm USD fork
FRONT BRAKE
4 pistons radial caliper with ABS
REAR SUSPENSION
Monoshock absorber / Single shock
REAR BRAKE
1 piston floating caliper / 1 piston floating caliper – 220 mm CBS or ABS
FRONT RIM TYPE
Alloy
REAR RIM TYPE
Alloy
REAR RIM DIMENSION
17 inch
FRONT TYRE
110 / 70-17 ”
REAR TYRE
140 / 70-17 ”
HEADLIGHT LAMP
LED
TAILLIGHT LAMP
LED
LENGTH
2000 mm
WIDTH
810 mm
HEIGHT
1070 mm
GROUND CLEARANCE
190 mm
UNLADEN WEIGHT
135kg
USABABLE TANK VOLUME
9.5L
WHEELBASE
1340 mm
SEAT HEIGHT
820 mm
Customer care goes above and beyond, and if you are not completely satisfied we will go out of our way to help you get the outcome you desire. Our friendly staff are available on the phone, via text or you can just use our contact form. We aim to respond to all queries within 24 hours. You can find out all our contact information here.
Extended Warranties
If your warranty has expired you can place a new warranty on your bike or scooter for further piece of mind. Unlike the manufacturers warranty these ones cover parts & labour at any VAT registered garage nationwide.
Delivery
Our fleet of specially equipped delivery vehicles ensure your bike or scooter delivers to your door with utmost care. Not to mention our driver’s will walk you around the vehicle giving advice and answering any questions you may have. Consequently as a result will give you more confidence with the vehicle. If you require delivery on this FB Mondial Piega, please add this product to your cart – Motorcycle Delivery
We are regulated and authorised to offer finance by the Financial Conduct Authority, you can see our authorised FCA License HERE.
All brand new vehicles are required by law to be registered prior to delivery. The only exception to this rule is on the condition you are purchasing the vehicle to use on private property. You can find information on registration and a number of other legal and rider requirements and even add this product to your cart here. The fee for having the new vehicle road worthy is £150. The new vehicle will be ready to ride, fully assembled, comprehensive safety check, road taxed, registered with the DVLA, 3 years MOT, full tank of fuel, L plates, Number Plate and thorough road test.
Reviews
There are no reviews yet.
